The surface finish required for the final product can dictate the milling operation selected. Operations like surface milling or slab milling can provide finer finishes. Aesthetic components might need a smooth finish achievable through high-speed milling.

The most cost-effective milling operation generally involves manual milling using conventional machines. This traditional approach does not require the sophisticated and costly technology of CNC systems, making it accessible for smaller shops and those with limited budgets.


Precision is paramount in many industries, and certain milling operations are better suited for tight tolerances. Precision engineering components like engine parts require high precision milling operations.

Angular milling, or bevel milling, is a precision machining process that involves cutting angles on the workpiece other than 90 degrees. This type of milling uses cutters, such as chamfer, angle, and dovetail cutters, which are shaped to produce specific angled cuts, allowing for complex shapes like V-shaped slots.

Among the various milling techniques, CNC (Computer Numerical Control) milling stands out as the most preferred due to its precision and versatility. CNC milling allows for the automated control of machine tools via software, ensuring high accuracy, repeatability, and production efficiency.

Reaming is a milling process used to improve the finish of a previously formed hole and to achieve a precise diameter. A reamer is used for this purpose, which is a rotary cutting tool with one or more cutting elements. It is used after drilling or other hole-making operations to achieve high precision and surface quality.


Drilling is a fundamental machining process where a drill bit is used to make a cylindrical hole in the workpiece. This operation is carried out on a drill press or a milling machine where the drill bit rotates at high speeds while being fed into a stationary workpiece, producing a round hole.

Side milling is a form of milling that involves the cutting tool removing material from the side of the workpiece. This operation uses side milling cutters or end mills to generate vertical walls and create side cuts with precise depth and width. The machines typically used are both horizontal and vertical milling machines, equipped with capabilities to handle side cutting with high precision.

Specialize in CNC machining, 3D printing, urethane casting, rapid tooling, injection molding, metal casting, sheet metal and extrusion

Plain milling, or slab milling, involves the rotation of a horizontally mounted cutting tool to produce a flat surface along the workpiece. This method is characterized by the use of a slab mill, which generally has straight cutting teeth on the periphery.

Conventional milling, often called up milling, is a process where the cutting tool rotates against the feed direction. This traditional method is less prevalent in high-production environments but remains invaluable for specific applications due to its simplicity and cost-effectiveness.

The most commonly employed type of milling is face milling. This method involves a milling cutter with teeth on the periphery and face, used primarily for creating flat surfaces. Face milling ensures efficient material removal and is widely applicable in various manufacturing processes where smooth finish and flatness are priorities.

CAM milling involves the use of computer-aided manufacturing software to control complex milling operations automatically. This technology allows for the precise milling of complex designs and is performed on CNC milling machines, which are programmed based on the CAM system’s outputs. The cutters are selected based on the specific requirements of the design, such as the complexity of the curves and the depth of the cut.

CNC milling represents the pinnacle of automation in machining processes. It involves the use of computerized instructions—derived from digitally input designs—to control the milling machinery. This advanced technology allows for the manipulation of milling cutters to create precise shapes and surfaces on the workpiece.

Slot milling is a process used to machine slots into the workpiece. It involves the use of end mills or slot drills to create a slot in a single pass, which can be straight or contoured. This type of milling is performed on both vertical and horizontal milling machines. It requires precision alignment of the cutter to the workpiece to ensure accurate slot dimensions and placement.

Cylindrical milling involves the rotation of a cylindrical milling cutter along the surface of a workpiece to cut a cylindrical shape. This operation is performed on both horizontal and vertical milling machines that accommodate cylindrical mills. The process is similar to turning, where the piece is rotated against the milling cutter, but here, the milling cutter is rotated along the cylindrical surface.

Ensure that the tools required for the milling operation are readily available and compatible with the milling machines. Some specialized operations might require custom or hard-to-find tools.

Profile milling involves the precision machining of the outer contours of a component. This process is typically performed using CNC machines that can maintain tight tolerances and complex shapes. The operation utilizes both end mills and face mills, depending on the type of profile required, making it versatile for detailed and intricate designs.

Form milling involves the use of milling cutters that have specially shaped teeth that can cut multiple grooves, flat surfaces, or irregular profiles into a workpiece. This process is typically used for milling complex forms in dies and molds, using cutters like convex, concave, and corner rounding milling cutters.

The availability of advanced machinery can open up possibilities for more complex and precise milling operations. Access to multi-axis CNC machines allows for advanced drilling and 3D shaping.

A milling operation involves using a machine equipped with a rotating cutting tool to remove material from a workpiece. The milling process is integral to manufacturing parts with precise dimensions and various shapes. The cutter typically moves across the workpiece or spins at variable speeds, allowing for detailed and accurate cutting.

Precision CNC milling is widely recognized as the most accurate milling operation. This method combines advanced CNC technology with high-precision tools to produce parts with exceptionally tight tolerances.

The most expensive milling operation is often 5-axis CNC milling. This technique requires advanced CNC machines capable of moving a workpiece or cutting tool along five different axes simultaneously. The complexity of the machinery involved, combined with the high level of skill required to operate these machines, drives up costs significantly.

Plunge milling is a focused milling operation where the cutting is performed more in a vertical manner than horizontally, engaging more of the end rather than the side of the cutter. This process involves the tool plunging axially into the side of a workpiece, typically used for making deep cavities in the manufacturing of molds and dies. The CNC machines designated for this operation are equipped with robust control systems to handle the significant force exerted during the plunge.

The oldest industrial milling technique is plain milling, also known as slab milling. Historically, plain milling was one of the first techniques developed and utilized in milling and remains a fundamental process in the machining and metalworking industries.

Boring is a precise operation in milling that utilizes single-point cutting tools to expand holes and achieve finer tolerances in diameter. This operation is performed using a boring bar, which is a tool typically equipped with multiple inserts that touch the workpiece at different radii, allowing for precise control of the hole size and surface texture.

Face milling is a machining process where the cutting tool’s axis is perpendicular to the surface of the workpiece, removing material to create flat surfaces. This operation is performed using a face mill, which contains multiple cutting edges on both the end and outside diameter of the tool.

Please choose your cookie settingsWe use cookies on our website. Some of them are necessary (e.g. for logging-in or the shopping cart), while others help us improve our website or advertise our products. You can accept all cookies, reject all cookies that require your consent or manage your preferences. You can manage your consent at any time by clicking on the cookies management link. For more information, please consult our privacy policy.

Thread milling is an intricate milling process used to create threads on the internal or external surfaces of a workpiece. This technique involves a rotating multi-point cutting tool that moves along a helical path to carve out the thread profile. Thread milling is particularly effective on CNC milling machines, providing superior precision and flexibility compared to tapping or threading dies.

Budget constraints can affect the choice of milling operation, with some being more cost-intensive due to equipment or labor costs. Conventional milling is often less expensive than CNC milling but might not meet all precision or complexity requirements.

Milling operations can be categorized based on the type of control used to operate the milling machine. This differentiation is crucial as it impacts precision, production speed, and the complexity of the tasks that can be accomplished. Below, we explore the primary types of control.

Each operation offers a unique capability, and to get your exact desired results, you need to figure out the best type of milling operation.

We use cookies on our website. Some of them are necessary (e.g. for logging-in or the shopping basket), while others help us to improve our website and better tailor the products to provide the best experience.

We use cookies on this site to enhance your user experience. By accepting you are giving your consent for us to set cookies on your computer. Learn More


Safety is crucial, especially in operations involving high-speed machines or hard materials. Operations that generate substantial heat or debris might require enhanced safety protocols.

Shoulder milling involves making perpendicular cuts along the edge of the workpiece to create a precise shoulder. This operation requires specialized cutters that can handle the intersection of two surfaces without damaging the piece. Machines used typically include vertical or horizontal milling setups, equipped with precise controls to ensure the shoulder’s accuracy.

The complexity of the part’s design, including the number of axes required for milling cutters to produce the shape, will affect the operation type. Complex aerospace components might require 5-axis CNC milling.

Climb milling, also known as down milling, involves the feed of the workpiece moving in the same direction as the cutting tool’s rotation. This method is preferred for its ability to produce a high-quality finish and extend tool life by minimizing tool deflection and heat generation.

Selecting the appropriate milling operation is crucial for optimizing performance, achieving precision, and managing costs. Each type of milling operation offers distinct benefits and is suitable for different applications, depending on a variety of factors.

The type of material you are working with significantly influences the choice of milling operation. Hard materials like stainless steel may require specific types of milling operations, such as carbide milling, to effectively handle the material’s hardness.

The type of cutter used is influenced by the material, the complexity of the cut, and the type of milling machine available. For example, end mills are used for profile milling, side milling, and face milling.

Straddle milling is a precise machining process where two or more parallel vertical surfaces are machined simultaneously with two side milling cutters. This method is typically used when full slots or a large surface area need to be milled on a workpiece at one setup, improving consistency and productivity. This operation requires sophisticated CNC milling machines capable of handling multiple cutters that precisely clear material from both sides of a workpiece.

End milling is a versatile machining process using a cutting tool known as an end mill that rotates on its axis while moving perpendicularly to the axis of the workpiece. This process allows for creating a variety of features such as slots, pockets, and contours. End milling can be performed on various milling machines, including both vertical and horizontal types, employing either high-speed steel or carbide tools.

The specific parameters and settings of a milling operation, such as speed and feed rate, are tailored based on the equipment and desired outcome. Higher feed rates are suitable for rough milling to remove material quickly.

The skill level of the operator can significantly influence the effectiveness of the milling operation. Complex CNC operations require highly skilled operators to program and monitor.

Angle milling, also known as angle face milling, involves cutting angles other than 90 degrees into the surface of a workpiece. This operation requires precision setup of the milling machine, using single-angle milling cutters or double-angle milling cutters, depending on the angle’s complexity and the production requirements.

Gear milling is a precision machining process specifically designed for creating gear teeth, using specialized tools and equipment. This operation involves either a form milling cutter or a hobbing process where the gear blank rotates as a cutter introduces the tooth profile. Modern gear milling utilizes advanced CNC machines to enhance accuracy and efficiency.

Manual milling involves the direct manipulation of the milling machine. Unlike CNC milling, where digital commands guide the machine, manual milling requires the operator to physically control the speed, direction, and depth of the cutter. This type of milling relies heavily on the machinist’s skill and experience.

Micro milling is an advanced manufacturing process where small, high-precision cutting tools are used to create intricate features on a workpiece. This technique utilizes CNC milling machines equipped with miniature end mills and drill bits, allowing for the creation of detailed and complex geometrical patterns. The accuracy of micro milling is supported by high-speed spindle rotation and fine tool control, making it ideal for achieving surface finishes with high dimensional accuracy.

Milling operations are diverse, each suited for different machining needs based on the shape, size, and features required in the finished part. Here’s a brief look at various types:

Milling operations are fast becoming a necessity in the manufacturing world. From transforming raw materials into desired shapes, milling operation plays a fundamental role in modern applications – including aerospace and automotive industry.

Certain cookies imply a transfer of your data to the US. By clicking on “Accept all”, you also agree in accordance with art.49 GDPR that your data is transferred to the US, whose legislation has been considered as not providing an adequate level of personal data protection and where your personal data could be processed by public authorities.

You can accept all cookies, reject all cookies that require your consent or manage your preferences. You can manage your consent at any time by clicking on the cookies management link. For more information, please consult our Privacy & Cookies Policy

The volume of parts needed can influence whether a more automated operation like CNC milling is more cost-effective than manual milling. Large production runs are more efficiently handled by CNC machines due to their automation and consistency.

We use cookies on this site to enhance your user experience. By accepting you are giving your consent for us to set cookies on your computer. Learn More

Helical milling is a process used to produce helical parts or grooves in the form of a helix on a cylindrical workpiece. This method involves rotating the milling cutter along a helix path, differing from conventional milling with its ability to perform cuts with continuous engagement. The helical milling process is ideal for creating complex geometries like drills, gears, and threads.

Gang milling refers to a process where multiple milling cutters are mounted on the same arbor, thus enabling more than one surface to be machined simultaneously. This arrangement enhances productivity by performing several milling operations in a single pass over the workpiece. The necessary machines for this operation are often complex and require precise setup to ensure alignment and accuracy of cuts.

You have a quote in your basket. We cannot merge this product with your quote. If you want to add this product to your basket your quote will be removed.

Saw milling involves the use of a circular saw blade to perform cutting operations, which is different from other milling techniques that typically involve rotary cutters. This method is especially useful for cutting long, straight cuts or grooves in materials. Saw milling machines are equipped with powerful motors to handle the heavy-duty cutting, ensuring clean and precise cuts.

F-Gas (Fluorinated gases) government regulations specify that a limited number of products can be sold in the European Union that contain F-gases which have been linked to climate change.

Milling operations are essential in shaping metals, and can be utilized even in woodworking for cabinetry and construction.
