“Because we’re talking about the heat generated, the quicker you can reduce the heat, the more aggressive you can be. Coolant is one means that you can reduce the heat in the cut. One thing we’ve developed, we call it our Jet HP line. It’s a high pressure coolant, tooling system. With our Jet HP line, people can run the coolant pumps up to 5,000 psi,” says Geisel.

Keep up to date with the latest news, events, and technology for all things metal from our pair of monthly magazines written specifically for Canadian manufacturers!

“When you’re running an interrupted cut in a turning situation, it’s almost always best to turn the coolant off and run dry [due to the risk of] thermal cracking,” states Mitchell.

To put it into perspective, that's 12.2km, or 7.58 miles - that's the height of Mount Everest and Mount Fuji put together.

The US started it in 1950 with the first serious plan to drill down into the mantle with the Soviets starting their efforts in 1970 and Germany following suit in 1990.

“We have a new Plura endmill optimized for high feed side milling. This tool also incorporates new coating process technology designed to keep the coating intact at higher speeds,” says MacNeil.

It took almost 20 years to drill that deep but the hole is only around one third of the way through the Earth's crust with temperatures already reaching 180 degrees Celsius (356 Fahrenheit).


The new-generation steel turning insert grades GC4425 and GC4415 deliver improved performance in every way. Coated with second-generation Inveio® technology, they have a broad range of applications and are recommended for continuous and interrupted cuts. See how our experts worked their magic and learn what drove them to create our recently launched ISO P steel turning grades – GC4415 and GC4425.

“High feed milling works well in a variety of materials including, but not limited to, carbon steels, alloy steels, stainless steels, heat resistant alloys, and titanium. Cutting conditions vary depending on the type of material,” says Paul Rice, applications engineer at Kyocera Precision Tools. “For example, slower feeds and speeds are used when machining heat resistant alloys and greatly increased when machining low carbon steels.”

“Until the process is secure and the programming suits the machine, material and fixturing, I don’t worry about wear. We can do a lot of damage before a tool wears,” says MacNeil. “To me it is the last factor left in the equation…wear is inevitable. Slow controlled wear that is predictable is the goal after we have everything else in the process secure.”

So, you want to maximize cutting speeds and feeds to reduce cycle times? If this is your goal, there’s a series of cutting tool factors to be considered, including coatings, coolant, materials, applications, etc.

“I always recommend the highest quality holder you can get,” says MacNeil. “High feed and speed is used to maximize metal removal rates. Investing in a high quality machine and programming methods and not investing in quality tools and holders … is equivalent to owning a Ferrari and putting the cheapest tires you can find on it. You won’t win the race, and you may end up with damaged components.”

Have your say in our news democracy. Click the upvote icon at the top of the page to help raise this article through the indy100 rankings.


“When it comes to high speed machining, we usually like to look at ALTiN [aluminum titanium nitride] coatings, primarily because of their heat resistance and their abrasion resistance,” says Jay Ball, product manager for solid carbide endmills, NAFTA at Seco Tools “In high speed machining, there’s a lot of heat generated.”

“Tungaloy recently expanded its DoOcto line…this milling cutter can now take a double positive eight-edged insert or an eight-edged high feed insert. The high feed insert can be used as a conventional milling tool when the depth of cut exceeds the recommended depth for high feed,” says Mitchell.

Heat has the greatest impact on tool life, and speed has the greatest impact on heat. With this in mind, we asked pundits about the role of coolant in maximizing speeds and feeds.

One final piece of wisdom: Morrison advises machinists looking to maximize speeds and feeds to take a moment to reflect before commencing work.

Speaking to the BBC, he said: "When the Russians started to drill they claimed they had found free water - and that was simply not believed by most scientists.

According to the BBC, locals say the hole, located near the Kola Peninsula in northwestern Russia near the border with northern Norway, is that deep they can hear the screams of souls tortured in hell.

It's reported there was no money to fund such projects after the collapse of the Soviet Union and three years later, in 1995, the whole facility was shut down.

“We have several new products out: Gold-Quad F and Gold-Quad XXX [high feed mills]. The first one, Gold-Quad F, is a 12-degree lead angle style tool. It does an excellent job of managing cutting forces and has up to seven different insert styles to address different milling scenarios,” says Fiorenza.

Drilling was stopped on the Kola Superdeep Borehole in 1992 when the 180 degrees Celsius temperature was reached, said to be twice the temperature expected at that depth, with drilling any further impossible as tools could not cope with the heat.

Tweaking the feedrate “depends on the situation…if you’re dealing with chip thinning, then yes you really need to ramp up your feed rate. If it’s not chip thinning, I’m not sure I would agree [with increasing the feedrate],” adds Mitchell.

“A low arc of engagement tends to lend itself to high speeds and feeds…reducing the contact area of a square shoulder tool keeps the heat low and allows us to increase feed to compensate for chip thinning that occurs at the low arc of engagement. An example of this is often called Trochoidal milling in slots but applies to any shape,” states Brian MacNeil, milling products and application specialist, Sandvik Canada. “Also Dynamic milling is a common method supported by CAM software that uses small arc of engagement with higher speeds and high feeds,” adds MacNeil.

We also wanted to know what materials work best in high speed/feed operations—and what materials are best machined slowly.

“Kyocera recently released an innovative high feed milling line-up. The MFH-Raptor and the MFH Mini high feed end mills and face mills utilize new insert grades with complex geometries that drastically reduce spindle loads and are capable of extremely high feed rates for maximum material removal,” says Rice.

“We have a new tool we’re releasing to the US market—the Brinkhaus ToolScope machine monitoring system. It monitors load on spindle, torque forces and other key indicators of machining performance,” says Morrison.

“Another option for finishing or semi-finishing is to use cermet,” suggests Mitchell. “Cermet is capable of running at higher speeds than carbide, produces excellent surface finish and lasts a very long time. Use CBN in hard turning applications. Some shops are still grinding their hardened parts. It is much faster to produce these parts on your CNC lathe using a CBN insert,” notes Mitchell.

Other tips from the experts: “Programming is the key in high feed milling,” says William Fiorenza, die and mold product manager at Ingersoll Cutting Tools. “Proper programming that utilizes high speed machining techniques and programing features such as corner welding and corner smoothing promotes free and smooth cutting and constant chip load. These are all key things you need to have to effectively high feed mill.”

Uli Harms is of the International Continental Scientific Drilling Program, who as a young scientist worked on the German rival to the Kola borehole.

“Pretty much all of our tools are designed with coolant through applications in mind,” says Cullen Morrison, business development manager at Komet of America. “We also have applications for MQL [Minimum Quantity Lubrication]…we’re looking at how can we run these components as fast and as stable as possible,” he adds.

Other tips: if maximizing high speeds and feeds is the goal, use a rigid machine tool—“As rigid as possible. Rigid will benefit everyone,” says Morrison.

A previous Canadian Metalworking story noted that on the first indication of premature tool wear, chatter or chipping, machinists will often turn down the override controlling the feedrate. In such situations, however, might it be better to boost the feedrate instead?

The Kola Superdeep Borehole is the deepest manmade hole, and deepest artificial point, on Earth, measuring at 40,230ft feet.

“I would say that’s very relative to what the process is … a low feed rate does cause increased wear. If that is the reason for the wear, then a higher feedrate would be better. If the cutting speed is too high, a higher feed rate is not going to help. If you’re talking about turning hardened steel at 60 Rc, the wear on the tool is just going to be a fact of life,” says Morrison.

“Almost every application lends itself to cycle time reductions,” says John Mitchell, general manager of Tungaloy Canada. “The options available to reduce cycle time are almost endless. When turning, the maximum feed rate should not exceed half of the insert nose radius, therefore use the largest nose radius possible to increase feed rates. If the part requires a good surface finish or has some corner radii restrictions, use a wiper insert.”

“We tell them, ‘look at everything as a system.’ Balance everything. You can’t put the cart in front of the horse. What are the limitations of the machine? What are its speed characteristics? You have to look at the whole system … it’s all about controlling the process,” states Morrison.

Easily access valuable industry resources now with full access to the digital edition of Canadian Fabricating & Welding.

“Obviously the faster the rpm, the shorter the tool life … but tool life is really a small player in total cost,” agrees Mitchell. “I think you’re always better off running as fast as you can, within reason. If you have to go in and index your insert every three minutes on the machine [then speed is not a benefit]. You have to balance tool wear and speed,” he says.

“CVD grades have a thicker coating and are better able to withstand heat in larger arcs of engagement and high speeds,” explains MacNeil. “PVD inserts are thinner and sharper which is better at low arcs of engagement. They do not withstand heat as well, but we have less heat in the process when the arc is low,” says MacNeil.

“Unfortunately, there’s really no tools that exist that allow you to take a very, very large depth of cut and also take a very, very aggressive feedrate. Because of the heat that’s generated, you either take a big depth of cut with a light feed or a small depth of cut with a high feed…you can only generate so much heat in a cut. The minute you generate more heat than what is needed, you’re going to burn out your cutting tool.”

“Higher than normal speeds and feeds can be applied to any material group by changing from conventional techniques,” suggests MacNeil. “Techniques allow for cutting data increases relative to material (for example, Titanium 6al4v at 250 sfm using standard toolpath can achieve 450-500 sfm with high feed side milling techniques),” he says.

“Typically when you deal with very, very high feed tooling, you’re also dealing with very, very light depths of cuts. So that’s the trade-off,” says Steve Geisel, senior product manager at Iscar Tools Inc.

“Be conscious of average chip thickness,” echoes Fiorenza. “All high feed tooling has a feed rate multiplier associated with the tool that is different for almost every cutter. That multiplier allows you to compensate for chip thinning. You do have to be aware of slowing down the feed rate and possibly generating too thin of a chip in which case you end up rubbing the material … it’s a very important thing for end users of high feed milling tools to understand what their feed rate multiplier is,” he says.

"There used to be common understanding among Western scientists that the crust was so dense 5km down that water could not permeate through it.”
