Greg has been with Techniks Tool Group for over 23 years serving in many roles from VP of Sales to President & CEO during which he has gained a deep understanding of CNC manufacturing processes and how to optimize tooling and workholding solutions for specific applications. He has written several articles, white papers, and blogs on various tooling, deburring, and workholding-related topics. As a recognized subject matter expert on CNC tooling, Greg is often approached to provide opinions and content for technical articles.

As the collet is pushed into the pocket by the collet nut, the slots in the collet allow the I.D. bore to collapse and apply clamping pressure to the cutting tool shank. The result is a very strong and rigid clamping force on the cutting tool. Since the collet base is tapered to match the collet pocket, tool runout (T.I.R.) is reduced.

All prices are in AUD Dollars and exclusive of GST unless otherwise stated. Agnew Building Supplies Pty Ltd ABN: 34618387161

If you are from the manufacturing or construction industries, the term “collets” is probably familiar to you. There are many types of collets used in many different industries and applications. For this article, we shall focus on collets used in rotary tool holders typically found in CNC machining (milling) centers.

Collets come in many different types and sizes. Here is an overview of three of the more popular types of collets, along with the pros and cons of each system.

As the collet experiences bell-mouthing, the cutting tool is allowed to deflect more and more during milling operations. Unfortunately, the collet may still indicate good accuracy on a presetter where there are no side-load forces. However, once the tool is put into service and begins experiencing side-load forces, the cutting tool is allowed more room to deflect, resulting in increased chatter and reduced tool life.

Collets are designed to wear out as they lose accuracy and rigidity with use. High side-load forces during milling operations cause cutting tool deflection as illustrated below.

It is critical to properly assemble the collet and collet nut to avoid damage to the collet and make the most accurate and rigid assembly possible. The extraction groove of the collet must be properly seated to the extraction ring of the collet nut.

Additionally, when the tool begins cutting and side forces are applied to the cutting tool, the cutting tool tends to deflect into the area where the faces are not clamping on the tool shank. This results in excessive chatter that dramatically reduces tool life and results in rough surface finishes. You will be hard-pressed to find a quality end mill holder manufacturer endorsing the performance of their tooling in DA collets.

The popularity of the ER collet system has led to several variations to hold a wide assortment of cutting tool shanks. Some ER collets have been modified with squares at the bottom to hold taps. Others have been modified to provide quick-change capabilities or compensation (also called “float”) for rigid tapping cycles as shown in the images below.

Rigorous independant testing has proven that the Gold Series Drills outperform other Australian drills on the market by more than 30% - giving you more holes for your dollar in every single drill bit !

Worn-out collets will not achieve the same level of accuracy and rigidity that newer collets can provide. The result is more chatter when cutting workpieces, less accuracy, and shorter cutting tool life. A good rule of thumb is to replace collets every 4-6 months to maximize the performance of your tooling. Again, collets are designed to wear out and are generally the least expensive component in the system. It is much less expensive to replace the collets as opposed to prematurely wearing out cutting tools.

As we continue to explain more about collets, it will first be helpful to understand the basic anatomy of collets and of a collet chuck system. The illustrations below will help provide a general understanding of the parts of a collet and collet chuck system.


Galling on the lead face of the collet can result in reduced clamping pressure on the cutting tool shank that may lead to the cutting tool slipping while cutting, or even tool breakage.

Collets are a high-precision wear component of a tool holding system and require maintenance to ensure accuracy. First, it’s important to remember that collets are the softest component in a collet-based tool-holding system assembly and are designed to wear out.

First, angle the collet so the extraction groove seats with the eccentric extraction ring in the collet nut as shown below.

Forming Techniks Tool Group with our partnership with Parlec has enabled us to deliver the most responsive customer service, and provide a one-stop-shop for cost-effective as well as high-precision, customizable CNC tool holding solutions for the Aerospace, Automotive, Medical, and Mold & Die industries.

Here is an overview of the wear pattern of a collet-based tool-holding system. The machine spindle is harder than the tool holder (a.k.a. collet chuck) that fits into the spindle, so any wear between these two components will mostly occur to the collet chuck. That’s good, as it protects the spindle from expensive maintenance. Collets are softer than both the collet chuck body and the cutting tool, so any wear forces between these items will mostly occur to the collet. Since collets are generally the least expensive component in a collet chuck tool holding system, it is preferred that the collets wear out before the other components.


One of the primary issues with DA collets is that they essentially clamp on the cutting tool shank with only two opposing faces in the I.D. bore. DA collets have four slots in the front of the collet and four slots in the back of the collet creating four clamping faces. However, when DA collets are tightened towards the lower end of their collapse range, two of the faces tend to be pushed out of the way so only two of the faces are clamping on the cutting tool shank. This may cause some runout at the nose when the tool is inspected in a presetter.

Before we get into the nuances of collets, it is vital to understand how collets work, what impacts their performance, how to maintain collets for long service life, and how to recognize when to replace them.

The ER collet system has become very popular due to the flexibility of the system to hold a variety of cutting tool shank types including drills, end mills, and taps. Also, ER collets provide several solutions for increasingly popular coolant-through cutting tools.

On the flip side, TG collets tend to have a bit more holding power than ER collets due to the collet base having a 4° taper as opposed to the 8° taper found in ER collets. This can make TG collets a good choice when machining with longer-length cutting tools.

The flute form, web thickness and split point of the standard Alpha drills are suitable for most materials forming fine chips. For effective drilling, the rigidity of the drilland work piece are most important. The shorter the flute length the more rigid the drill. Long drills must be adequately supported to reduce vibration.

Techniks Inc. prides itself on delivering the industry’s best service & support, and providing a wide array of cost effective, high production cnc toolholding solutions.


The tapered collet base is made to fit into the collet pocket of the collet chuck body. The tapered design of the collet base and collet pocket allows the collet to be centered in the pocket as it is pushed in by the collet nut during setup. This centering effect enables the collet to achieve a high degree of accuracy (concentricity); much more than drill chucks and side-lock style holders.

TG collets have about the same accuracy as DA collets, but because there are more slots, and therefore more faces clamping on the cutting tool shank, they tend to deliver greater holding power. TG can be a good solution for larger shank diameter cutting tools, but they generally limit how far down into a pocket you can reach due to interference with the collet nut, as TG collet nuts tend to be quite large.

TG collets are not as popular as ER collets for several reasons. Most notably, the larger diameter collet nuts can require the use of extended end mills to avoid interference from the collet nut when milling pockets. Also, since TG collets have a very small collapse range, they are intended for use with one size cutting tool shank. ER collets, by contrast, offer a large collapse range that can be helpful when clamping odd-shank diameter tools.

This is exactly where Techniks Tool Group can help! Offering a wide range of collets and collet chucks, our experts will help guide you to the best solution for your needs. Our collets are trusted by some of the largest manufacturers in the world. Check out our collets and get started on your journey!

Next, while holding the collet and nut together, place the assembly in the tool holder and begin tightening the nut. If the collet extraction groove is not properly seated to the collet nut extraction ring, the collet will appear seated below the face of the nut. This typically occurs when the collet is placed in the collet pocket of the tool holder and then the nut is threaded on the tool holder. In a correct assembly, the collet will seat at the face of the collet nut. The image below shows a correct assembly on the left and an incorrect assembly on the right.

It is recommended to change collets out every 4-6 months, depending on usage, to ensure the most rigid and accurate collet chuck assembly.

This is not rust but rather an indication that there is a vibration between the collet and the collet pocket connection. The vibration causing the fretting is also reducing cutting tool life. If you see signs of fretting on the collet, it is advised to replace the collet. You should also ensure that collet nuts are tightened to the correct torque specifications during setup.

Collets are the critical connection between the cutting tool and the tool holder (also called a collet chuck). Most collets are round, cone-shaped, and slotted. Collets encircle the cutting tool shank to evenly distribute holding power around its center bore.

Yes. Any signs of fretting on the collet indicate the collet is vibrating in the tool holder. Fretting appears as rust-colored spots typically at the highest point where the collet sits in the collet pocket of the collet chuck.

DO NOT tighten the collet nut if the collet appears seated below the face of the nut as this will create galling on the 30° face of the collet. Galling appear as grooves or lines in the lead face of the collet.

Other modifications include special slotting designs that seal around the cutting tool shank and force coolant through channels in coolant-through tooling, as well as modifications to include coolant ports in the collet that direct coolant to the cutting area.

Most standard ER collets have between a 0.020” and 0.040” holding range, making them a good choice when needing to hold odd-sized cutting tool shanks. This holding range also means fewer ER collets are required to hold a range of cutting tool shank diameters as opposed to other collet systems like TG.

Given the wide range of benefits offered by collets, they are one of the most indispensable tools in the manufacturing industry. To get the most from your collet-based tooling system, it is important to use best-in-class products to produce top-notch quality.

Double-Angle (DA) collets have been around for a long time and continue to be used in the market. There are, however, many issues associated with DA collets of which users should be aware.
