Coarsevsfine threadchart

The difference between coarse thread and fine thread screws is mainly in the pitch, which is the distance between the threads on the screw. Coarse thread screws have a larger pitch, meaning that they have fewer threads per inch, while fine thread screws have a smaller pitch, meaning that they have more threads per inch.

Difference between fine thread and coarse threadchart

Not enough Inventory? Submit your email address and desired total quantity below, and we will notify you when stock arrives.

Difference between fine thread and coarse threadfor steel

Coarse thread screws are more suitable for brittle materials, such as wood or plastic, because they are less likely to cause cracking or splitting. They are also easier to install and remove, and more resistant to damage or dirt. Fine thread screws are more suitable for strength applications, such as metal or hard plastic, because they have a higher tensile and shear strength. They are also less prone to loosening from vibration, but they require more torque and precision to install.

One of the first agreed international standards for industry was ISO 68-1. Set up in 1947 it describes the basic dimensions of threaded components. For tolerance information, those are detailed in ISO 965-1. The standard ISO 261 details the common combinations of major diameter and pitch for metric threads.
